SPECIFICATIONS

• Power Output : 1.0 HP (0.75 kW)
• Winding Core Material : 99.99% Pure Enameled Electrolytic Copper (Cu)
• Operating Speed : 2800 – 2900 RPM
• Operational Voltage Range : 160V – 240V (Single Phase AC, 50 Hz)
• Total Head Delivery Range : 6 Meters up to 56 Meters
• Discharge Volume Flow Rate : Up to 3924 Liters Per Hour (LPH) / 65 LPM
• Pipe Connections (Inlet × Outlet) : 25 mm × 25 mm (1" × 1")

MATERIAL OF CONSTRUCTION (MOC)

• Motor Stator Winding : 100% Dual-Coated Copper Wire
• Motor Frame/Body : Extruded Aluminium / High-Tensile Graded Cast Iron
• Pump Shell & Bracket : Fine Grained Cast Iron (High Mechanical Tensile Strength)
• Fluid Impeller Profile : Precision Machine-Forged Brass STAR Type

SALIENT PRODUCT FEATURES

• Advanced Corrosion Immunity : Cast Iron components undergo advanced Cathodic Electro Deposition (CED)
• Burnout Protection Shield : Outfitted with an automatic Thermal Overload Protector (TOP) core safety element embedded directly in the copper coils.
• Insulation Integrity Rating : Class 'B' & Class 'F' thermal materials shield against electrical winding wear.
• Pre-Lubricated Mechanics : Double-shielded heavy-duty ball bearings reduce systemic frictional friction without oiling.
